Simple Miniature Motor Controller by LM317
The LM317 is a versatile adjustable voltage regulator that can provide a stable output voltage over a wide range of input voltages, making it suitable for various applications, including dosing pumps. The device can deliver output currents of up to 1.5A, depending on the thermal conditions and external components used.
In a typical configuration, the LM317 requires two external resistors to set the desired output voltage. The formula for calculating the output voltage (Vout) is given by:
Vout = Vref * (1 + R2/R1) + Iadj * R2
where Vref is typically 1.25V, R1 is connected between the output and the adjustment pin, and R2 is connected from the adjustment pin to ground. The output voltage can be adjusted by selecting appropriate resistor values for R1 and R2.
Additionally, when designing a circuit with the LM317, it is essential to include input and output capacitors to ensure stability and transient response. A 0.1µF capacitor at the input and a 1µF capacitor at the output are commonly recommended. Heat dissipation must also be considered; therefore, a heat sink may be necessary if the power dissipation exceeds the junction-to-ambient thermal resistance.
The use of a 24V DC power supply allows for a broad range of applications, as it provides sufficient headroom for the LM317 to regulate the output voltage effectively. The ability to adjust the output voltage to 1.25V is particularly useful in dosing pump applications, where precise control of fluid delivery is required.
In summary, the LM317 circuit in a dosing pump control application is an efficient solution for voltage regulation, providing flexibility and reliability in controlling the output voltage for various operational needs. Proper component selection and thermal management are key factors in ensuring optimal performance of the circuit.I got this from a dosing pump control circuit. we use cool IC is no. lm317 circuit, It can uses with power supply source 24VDC and adjust voltage output 1.25V.. 🔗 External reference
