TDA2030 35 watt audio amplifier circuit

This TDA2030 35-watt audio amplifier circuit project is designed to deliver an output power of 35 watts into an 8-ohm load. The TDA2030 is a monolithic integrated circuit housed in a Pentawatt package, intended for use as a low-frequency Class AB amplifier. It provides high output current while maintaining very low harmonic and crossover distortion. This 35-watt power amplifier requires a well-filtered DC power supply that delivers an output voltage of ±16 volts. This circuit allows for the design of a simple and efficient subwoofer amplifier with a maximum output power of 35 watts. The device includes a short-circuit protection system that automatically limits the dissipated power to keep the output transistors within their safe operating area. Additionally, a conventional thermal shutdown system is incorporated.

The TDA2030 amplifier circuit is characterized by its robust design, making it suitable for various audio applications, particularly in subwoofer systems. The circuit's architecture typically includes the TDA2030 IC, a few passive components such as resistors and capacitors, and a power supply section. The input stage of the amplifier receives audio signals, which are then amplified by the TDA2030. The output stage is designed to drive an 8-ohm speaker, providing sufficient power while ensuring fidelity in sound reproduction.

To ensure optimal performance, the power supply must be capable of delivering a stable ±16 volts, which is essential for the proper functioning of the TDA2030. This power supply should be well-filtered to prevent noise and ensure clean audio output. The circuit may also include additional components such as bypass capacitors to further enhance stability and reduce power supply noise.

The inclusion of a short-circuit protection system is a critical feature, as it prevents damage to the amplifier in case of load faults. This system monitors the output current and can reduce the power dissipated by the output transistors, maintaining the integrity of the device. The thermal shutdown system serves as an additional safeguard, automatically disconnecting the output if the temperature exceeds a predetermined threshold, thus protecting the amplifier from overheating.

Overall, the TDA2030 35-watt audio amplifier circuit is a reliable solution for audio amplification needs, particularly in applications requiring low-frequency response and high output power, such as subwoofer setups. Its design simplicity combined with protective features makes it an appealing choice for both hobbyists and professionals in the audio engineering field.This TDA2030 35 watt audio amplifier circuit project is designed to provide an output power of 35 watts on to a 8 ohms load. The TDA2030 is a monolithic IC in Pentawatt package intended for use as low frequency class AB amplifier.

The TDA2030 provides high output current and has very low harmonic and cross-over distortion. This 35 watt power amplifier require a very good filtered DC power supply , that will provide an output voltage of +/- 16 volts .

Using this circuit you can design a very simple and efficiency subwoofer amplifier with a maximum output power of 35 watt power . The device incorporates a short circuit protection system comprising an arrangement for automatically limiting the dissipated power so as to keep the working point of the output transistors within their safe operating area.

Also a conventional thermal shut-down system is also included .
