wideband output amplifier circuit
The wideband output amplifier circuit is designed to effectively drive a 50-ohm transmission line, making it suitable for high-frequency applications. The CA3140 operational amplifier is a key component, chosen for its high slew rate and bandwidth capabilities. The circuit configuration typically includes feedback resistors to set the gain and ensure stability across a wide frequency range.
In operation, the amplifier can achieve an output of 18V peak-to-peak when not loaded, allowing for significant voltage swings that can accommodate various signal types. When connected to a 50-ohm load, the output is reduced to 9V peak-to-peak, which is an important consideration for maintaining signal integrity and minimizing reflections in transmission lines.
The specified slew rate of 28V/µs indicates the speed at which the output can change, which is critical for handling rapid signal transitions without distortion. This performance is particularly relevant in applications such as RF transmission, where signal fidelity is paramount.
The circuit may also incorporate bypass capacitors near the power supply pins of the CA3140 to filter out noise and stabilize the supply voltage. Additionally, proper layout techniques should be employed to minimize parasitic inductance and capacitance, which can adversely affect the amplifier's performance at high frequencies. Overall, this wideband output amplifier design is a robust solution for driving 50-ohm loads in various electronic applications.This is a simple design for wideband output amplifier. The wideband amplifier is suitable for use as a 50 © transmission line driver. This circuit is built by CA3140. This is the figure of the circuit. This circuit, when used in conjunction with the function generator and sine wave shaper circuits shown in Figures 10 and 12 provides 18VP-P output open circuited, or 9VP-P output when terminated in 50 ©. The slew rate required of this amplifier is 28V/ s (18VP-P x x 0. 5MHz). 🔗 External reference
