1996Ford Windstar: connector console thebucketseats 12volts

A 1996 Ford Windstar has a connector at the bottom of the console between the bucket seats that reads 6 volts (using a voltmeter) instead of the 12 volts expected from a cigarette/accessory connector. The 6 volts is stable, and there are two cigarette lighter connectors available that yield 12 volts. Information about where to find a schematic or details regarding this connector is sought, as the owner's manual only provides a text listing. It is noted that the individual is not in need of three 12V connector ports; they simply want to know how to obtain schematic information about this connector port and the proper voltage specification for it. Repair costs at a Ford dealer are considered excessive for this simple issue. The connector is located at the base of the 1996 Windstar console and is not a cigarette lighter; it appears to be an accessory connector for cigar-type power inverters or vehicle chargers. The power at the console measures 6 volts, leading to the main inquiry about where to find a schematic that defines the proper voltage for this console connector. Instructions are provided for testing the voltage: connect a voltmeter between a good ground and the power supply wire to measure 6 volts, then connect a test bulb (12V) between the ground and the power supply wire. If the voltmeter reading drops to zero volts, it indicates a bad contact somewhere in the power supply circuit. The voltage should first be checked at Fuse #22. The power plug is in parallel with the rear cigar lighter, which provides 12 volts, while the power plug at the console is 6 volts due to a bad connection issue.

The connector located at the base of the console in the 1996 Ford Windstar is designed to provide power to various accessories, such as vehicle chargers or inverters. It is expected to output a voltage of 12 volts, similar to the rear cigarette lighter connectors. The observed voltage of 6 volts indicates a potential issue in the power supply circuit, which could stem from a faulty connection, a blown fuse, or an internal wiring problem.

To diagnose the issue, the first step involves measuring the voltage at the connector with a voltmeter. The voltmeter should be connected between a reliable ground and the power supply wire of the connector. If the reading is 6 volts, it suggests that the circuit is partially operational but not delivering the expected voltage. Following this, connecting a 12V test bulb between ground and the power supply wire can help identify bad connections. If the bulb does not illuminate or the voltmeter reading drops to zero, it confirms a fault in the circuit.

Checking Fuse #22 is critical, as a blown fuse can disrupt power to the console connector. If the fuse is intact and the voltage remains at 6 volts, further investigation into the wiring and connections leading to the console connector is necessary. Inspecting for loose connections, corrosion, or damaged wires may reveal the cause of the voltage drop.

For schematic information, it is recommended to consult a service manual specific to the 1996 Ford Windstar, which would provide detailed wiring diagrams and voltage specifications for various connectors throughout the vehicle. Such manuals can often be found at automotive parts stores, online retailers, or through Ford dealerships. Additionally, online forums or communities focused on Ford vehicles may offer shared resources or insights from other owners who have encountered similar issues.A 1996 Ford Windstar and the connector at the bottom of the console between the bucket seats reads 6 volts (VOM) and not the 12 volts expected from a cigarette/accessory connector. The 6 Volts is solid and 2 cigarette lighter connectors are available the yield 12 volts. Where can I find a schematic or information about this. The owners manual is only a text listing. Edit: this is my Maiden voyage on Just answer. com; I am not in need for 3 12v connector ports; I just want to know how to get schematic information about this connector port; Proper voltage specification on this port; the repair costs at a Ford dealer would be out of line for this simple problem; I need to buy a Ford electrical Schematic for a 1996 windstar The connector is a the base of the 1996 Windstar console and is not a cigar lighter. the connector appears to be an Accessory connector for cigar type power invertor of vehicle chargers.

The Power at the console is 6 volts I Believe my real question is only where can i get a schematic that defines the proper voltage for this console connector. I am looking for the Accept button Connect your voltmeter between a good ground and the power supply wire = you will get 6 Volt, then connect a test bulb ( usual 12V bulb) between the ground and this power supply wire.

If your voltmeter readings drops to zero volts, you have a bad contact somewhere in the power suplly circuit. At first check the voltage at the Fuse#22. Thank You. I will type Accept button. the power Plug is in Parrallel with the rear cigar lighter. The Rear cigar lighter power is 12 volt AOK. the power Plug is 6 volt with a bad connection problem. With Me luck and than you very much. Ask-a-doc Web sites: If you`ve got a quick question, you can try to get an answer from sites that say they have various specialists on hand to give quick answers.
