18W + 18W Stereo Hi-Fi Audio Amplifier (TDA2030) circuit
The 2 x 18W Hi-Fi Stereo Power Amplifier circuit utilizes two TDA2030 ICs, which are well-regarded for their high performance in audio amplification applications. Each TDA2030 can deliver up to 14W of output power into an 8-ohm load, making it suitable for driving small to medium speakers effectively. The amplifier's design incorporates features that enhance audio fidelity and reliability.
The input stage of the amplifier typically includes capacitive coupling to block any DC offset from the source, ensuring that only the intended audio signal is amplified. Following the input stage, the TDA2030 ICs amplify the audio signal while maintaining low distortion, which is crucial for high-fidelity audio reproduction. The output stage is designed to handle the power requirements of the connected speakers, with the ability to drive both 4-ohm and 8-ohm loads.
Protection mechanisms are integrated into the circuit to prevent damage caused by overloads or short circuits. This includes thermal shutdown features, which automatically reduce the output power if the ICs reach unsafe temperatures, and short-circuit protection that disconnects the output in the event of a fault. These features ensure the longevity and reliability of the amplifier in various operating conditions.
The power supply requirements of ±18Vdc/3A are essential for the proper functioning of the amplifier. A regulated power supply is recommended to maintain consistent voltage levels, which contributes to the overall performance and stability of the amplifier. The symmetrical power supply allows for balanced operation of the TDA2030 ICs, facilitating improved audio performance.
In summary, this 2 x 18W Hi-Fi Stereo Power Amplifier is an effective solution for enhancing audio systems, whether as a standalone amplifier or as part of a more extensive audio setup. Its robust design and protective features make it a reliable choice for audio enthusiasts seeking quality amplification.2 x 18W Hi-Fi Stereo Power Amplifier based around two TDA2030 ICs. It has good input sensitivity, low distortion, good operating stability and full protection against overloads and output short-circuits. It can be used as a booster amplifier for existing small systems or to drive a second pair of speakers besides the ones already connected to the system.
The board needs a symmetrical power supply of ±18Vdc/3A and can be connected to loads of 8 or 4 Ohm.. 🔗 External reference
