1W stereo Headphone Amp (TDA2822)
The described stereo power amplifier is intended for applications in portable audio devices, such as players and radios. It features a dual voltage supply capability, allowing it to operate effectively with both 3V and 9V power sources, making it versatile for different audio output requirements.
When powered by a 3V supply, the amplifier is optimized for headphone usage, delivering an output power of 20mW per channel into 32 Ohm headphones. This level of power is suitable for personal listening, ensuring adequate volume levels while maintaining sound quality without distortion. The design likely includes a Class AB output stage to balance efficiency and linearity, which is crucial for high-fidelity audio reproduction in portable devices.
In contrast, when the amplifier is supplied with a 9V power source, it can provide a significantly higher output power of 1W per channel into 8 Ohm small loudspeakers. This increased power capability allows the amplifier to drive larger speakers, making it suitable for applications where higher sound levels are required, such as in small portable speaker systems. The circuit may include features such as thermal protection and short-circuit protection to ensure reliability and durability under varying load conditions.
The amplifier's design would typically incorporate a feedback loop to enhance linearity and reduce harmonic distortion, contributing to a clearer sound output. Additionally, components such as capacitors and resistors would be carefully selected to optimize frequency response and transient response, ensuring that the amplifier performs well across a range of audio frequencies.
Overall, this stereo power amplifier is a practical solution for enhancing audio output in portable applications, capable of adapting to different power supply configurations while delivering quality sound performance.A stereo power amp designed for use in portable players and radios. A 3V supply can be used to drive headphones providing 20mW in 32 Ohms per channel.
A 9V supply will provide 1W in 8 Ohm per channel for small loudspeakers.
