20 Watt Audio Amplifier
The described audio power amplifier is a straightforward design aimed at hobbyists seeking to create their own audio amplification solution. The amplifier operates at a power output of 20 watts, making it suitable for driving small to medium-sized speakers in a home environment.
Key components of the circuit include L1, which is likely an inductor or transformer designed to handle a peak current of up to 4A. This current rating is crucial for ensuring the amplifier can drive speakers at full load without overheating or failing. The circuit's low distortion rating of 0.015% at a frequency of 1 kHz indicates high fidelity, meaning the amplifier can reproduce audio signals with minimal alteration, preserving the integrity of the original sound.
Protection features are incorporated into the design to safeguard against both AC and DC short circuits to ground. This is an essential aspect of circuit design, as it helps prevent damage to the amplifier and connected speakers in the event of a fault condition. The protection mechanisms may involve fuses or circuit breakers that disconnect the power supply when an overcurrent condition is detected.
The schematic for this amplifier would typically include a power supply section, which converts AC mains voltage to the required DC voltage levels for the amplifier circuitry. The amplifier stage itself would consist of transistors or operational amplifiers configured to provide the necessary gain and output power. Additionally, coupling capacitors may be used to block DC while allowing AC audio signals to pass through to the output stage.
Overall, this audio power amplifier circuit is a practical project for electronics enthusiasts, providing a balance of performance, simplicity, and safety features for effective audio amplification.This simple 20 watts audio power amplifier is designed for home-brewed purpose. The L1 should be able to handle a current up to 4A to drive speaker in full load. The distortion is 0.015% @ 1KHz / 20W. This circuit is protected for AC and DC short circuits to ground. 🔗 External reference
