BA5417 Mini Stereo Power Amplifier Diagram

The BA5406 is a dual OTL (output transformerless) monolithic power integrated circuit (IC) featuring two high-output speaker amplifier circuits. It operates effectively with a supply voltage (Vcc) of 12 V and a load resistance (Rl) of 3 Ohms. At a supply voltage of 9 V and a load resistance of 3 Ohms, this circuit can deliver an output power of 2.8 W per channel. The IC is designed with a high allowable power dissipation package, facilitating a straightforward heatsink configuration. It not only surpasses fundamental performance characteristics but also incorporates a built-in soft clipping circuit.

The BA5406 is engineered for audio amplification applications, particularly in consumer electronics such as television sets, radios, and portable audio devices. The dual amplifier configuration allows for stereo sound reproduction, making it suitable for applications where space and power efficiency are critical.

The output stage of the BA5406 is designed to drive low-impedance speakers directly, eliminating the need for output transformers. This design choice contributes to the compactness and efficiency of the circuit. The soft clipping feature is particularly advantageous in preventing distortion during high signal peaks, thereby enhancing sound quality and listener experience.

For optimal performance, the power supply should be stable, with decoupling capacitors placed near the power pins of the IC to minimize noise and ensure reliability. The device is also capable of operating in various thermal conditions due to its robust package design, which allows for effective heat dissipation.

In terms of connection, the BA5406 requires a few external components, such as input coupling capacitors and feedback resistors, to set the gain and frequency response according to application needs. The layout of the circuit board should be carefully designed to minimize inductive and capacitive coupling, which could affect the performance of the amplifier.

Overall, the BA5406 offers a versatile solution for high-quality audio amplification in compact electronic devices, with features that enhance both performance and usability.The BA5406 is a dual OTL monolithic power IC with two built-in, high outpout speaker amplifier circuits. The power can be produced when Vcc = 12 V and Rl = 3 Ohm. And when Vcc = 9 V, Rl = 3 V, this circuit produce 2. 8 Wx2. This IC, which uses a high allowable power dissipation package, has a simple heatsink design. Not only exceeds basic characteristics, but also has abuilt-in soft clip circuit, 🔗 External reference
