Latest Intruder Alarm Super Sensitive circuit and explantion

The circuit diagram illustrates an ultra-sensitive intruder alarm. The mere shadow of an intruder passing within a few meters of the circuit is sufficient to activate the alarm. In this setup, the IC2 uA741 is configured as a sensitive comparator, with the set point determined by resistors R6 and R7. The voltage division created by the LDR (Light Dependent Resistor) and R9 is applied to the non-inverting pin of IC2. In standby mode, these two voltages are balanced by adjusting R9. Consequently, the output at pin 6 of the comparator remains high, keeping transistor Q1 off. The voltage at the trigger pin of IC1 is positive, resulting in no alarm activation. When an intruder approaches the LDR, the shadow cast increases its resistance.

The ultra-sensitive intruder alarm circuit employs a uA741 operational amplifier configured as a comparator to detect changes in light intensity caused by an intruder's shadow. The LDR, which is sensitive to light, is paired with a fixed resistor (R9) to create a voltage divider that feeds into the non-inverting input of the uA741. Resistors R6 and R7 set the reference voltage level against which the LDR voltage is compared.

In normal operation, the circuit is calibrated such that the voltage across the LDR and R9 is equal to the voltage set by R6 and R7. This balance keeps the output of the uA741 high, which turns off transistor Q1, preventing the alarm from sounding. The alarm remains inactive until a change in light intensity occurs, which is detected when an intruder's shadow increases the resistance of the LDR.

As the shadow falls on the LDR, the voltage at the non-inverting input drops below the reference voltage, causing the output of the comparator to switch low. This transition turns on transistor Q1, which can be configured to activate an alarm system, such as a siren or a notification system. The design allows for sensitivity adjustments through R9, enabling the user to fine-tune the response threshold based on environmental lighting conditions and desired sensitivity to intrusions.
